"SeaRover Escape"

by Volker Gries

DIESEL ELECTRIC HYBRID LONG RANGE VESSEL

"SELF-RIGHTING"

Loa: 18.20 m - Beam: 5.25 m - Draft: +- 1.45 m - Displmt. 71 mt (full loaded).

Propulsion: 2 x 225 kW Diesels - 2 x 120 Volt - 176 kW Generators,

2 x 176 kW elektric driven POD´s with Nozzles.

360 deg.  "POD Power Save Technology" - PPST - .

Batteries: Lithium-ion or Solid State - customized


Azimut

Volume Displacement = 71.0551

Center of Buoyancy = 8.32574, 2.48735e-10, 0.943794

Wetted Surface Area = 106.871

Waterline Length = 17.4861

Maximum Waterline Beam = 5.26548

Water Plane Area = 79.6786

Center of Floatation = 7.92995, 2.21955e-12,1.45

Fuel 9,000 liters +

Vel [kts]

Rw/W

Rr/W

Rbare/W

Rw [kN]

Rr [kN]

Rbare [kN]

PEbare [kW]

2

0

0.00022

0.00046

0

0

0

0

4

0

0.00088

0.00171

0

1

1

2

6

0

0.00269

0.00445

0

2

3

10

8

0

0.00867

0.01167

0

6

8

33

10

0

0.02666

0.03118

0

19

22

112

12

0

0.07296

0.0793

0

51

55

341

14

0

0.17699

0.18544

0

123

129

930



Information:

Volker Gries - N.A.-M.E.

 http://www.grivo.eu
